Desktop Computer Processor J4105 SR3S4 Processor ( 4MB Cache 2.5GHz ) Computer CPU Chip

Basic Information
Certification: Original Parts
Model Number: J4105 SR3S4
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: 10cm X 10cm X 5cm
Delivery Time: 3-5 work days
Payment Terms: T/T, PayPal, Western Union, Escrow and others
Supply Ability: 500-2000pcs per month
Detail Information
Model Number: J4105 Product Collection: Intel Celeron Processor J Series
Code Name: Products Formerly Gemini Lake Market Segment: Desktop
Status: Launched Lithography: 14nm
Launched Date: Q4'17 Use Condition: Desktop PC
High Light:

desktop pc cpu


desktop computer cpu

Product Description

Desktop Computer Processor J4105 SR3S4 Processor ( 4MB Cache 2.5GHz ) Computer CPU Chip

Celeron J4105 is a quad-core desktop SoC primarily for mini PCs and mini ITX mainboards. It runs at 1.5 - 2.5 GHz (Single Core Burst) and is based on the Gemini Lake platform. Similar to the Apollo Lake predecessor, the chip is manufactured in a 14 nm process with FinFETs but offers slightly improved processor cores, double the amount of L2 cache, a smaller package, a new generation of monitor outputs (Gen 10) and a partly integrated WiFi chip. Besides four CPU cores, the chip also includes a DirectX 12 capable GPU as well as a DDR4/LPDDR4 memory controller (dual-channel, up to 2400 MHz). The SoC is not replaceable as it is directly soldered to the mainboard.

Processor number J4105

Processor number J4105
Family Celeron
Technology (micron) 0.014
Processor speed (GHz) 1.5
L2 cache size (KB) 4096
The number of cores 4
EM64T Supported
HyperThreading technology Not supported
Virtualization technology Supported
Enhanced SpeedStep technology Supported
Execute-Disable bit feature Supported



General information:

Type System-on-a-Chip
Market segment Desktop
Intel Celeron (Gemini Lake)
Model number J4105
Frequency 1500 MHz
Maximum turbo frequency 2500 MHz (1 core)
2400 MHz (2 cores)
Low power frequency 800 MHz
Package 1090-ball Flip-Chip Ball Grid Array (Type 3)
Socket BGA1090
Size 0.98" x 0.94" / 2.5cm x 2.4cm
Introduction date December 11, 2017


Architecture / Microarchitecture:


Microarchitecture Goldmont Plus
Processor core Gemini Lake
Core stepping B0 (SR3S4)
Manufacturing process 0.014 micron
Data width 64 bit
The number of CPU cores 4
The number of threads 4
Floating Point Unit Integrated
Level 1 cache size 4 x 32 KB 8-way set associative instruction caches
4 x 24 KB 6-way set associative data caches
Level 2 cache size 4 MB 16-way set associative shared cache
Level 3 cache size None
Physical memory 8 GB
Multiprocessing Uniprocessor
Extensions and Technologies
  • MMX instructions
  • SSE / Streaming SIMD Extensions
  • SSE2 / Streaming SIMD Extensions 2
  • SSE3 / Streaming SIMD Extensions 3
  • SSSE3 / Supplemental Streaming SIMD Extensions 3
  • SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4
  • AES / Advanced Encryption Standard instructions
  • EM64T / Extended Memory 64 technology / Intel 64
  • VT-x / Virtualization technology
  • VT-d / Virtualization for directed I/O
  • BPT / Burst Performance technology
Security Features
  • NX / XD / Execute disable bit
  • MPX / Memory Protection Extensions
  • SGX / Software Guard Extensions
Low power features
  • Core C1/C1E, C6, C6L, C7, C7L, C8, C9 and C10 states
  • Module MC0-CC6 and MC7 states
  • Enhanced SpeedStep technology


Integrated peripherals / components:

Display controller
  • 3 displays
  • MIPI-DSI 1.2 / DP 1.2a / HDMI 2.0a / eDP 1.4
  • DP, HDMI and eDP interfaces support up to 4096x2160 at 60 Hz
Integrated graphics GPU Type: Intel UHD 600
Microarchitecture: Gen 9 LP
Execution units: 12
Base frequency (MHz): 250
Maximum frequency (MHz): 750
Memory controller The number of controllers: 1
Memory channels: 2
Channel width (bits): 64
Supported memory: DDR4-2400, LPDDR4-2400
Maximum memory bandwidth (GB/s): 38.4
Other peripherals
  • PCI Express 2.0 interface (6 lanes)
  • HD Audio
  • eMMC interface
  • I2S interface
  • I2C controler
  • SPI interface
  • LPC interface
  • High-Speed UART
Supported interfaces
  • USB 3.0 interface (6 ports)
  • USB 2.0 interface (8 ports)
  • SATA 3.0 interface (2 ports)


Electrical / Thermal parameters:

Minimum/Maximum operating temperature 0°C - 105°C
Thermal Design Power 10 Watt
